SOG (Synchronization On Green)

A properly functioning color monitor requires five kinds of signals: horizontal sync pulse, vertical sync pulse,

red color signal, green color signal and blue color signal. Signals from a PC are transmitted to a monitor

using one of three methods:

1. Separate sync: Horizontal and Vertical sync signals transmitted separately

2. Composite sync: Horizontal and vertical sync pulses mixed into a single signal train.

3. SOG: Horizontal and vertical sync pulses mixed, then combined with the green color signal.

RETURN TO TOP OF THE PAGE

TCO

See Electromagnetic radiation standards.

Tilt function

Glossary

file:///D|/EDFU/LF3/lf3manual/english/GLOSSARY/GLOSSARY.HTM (14 of 18) [2002/9/2 ?? 04:08:32]
